Oil Resistant Conveyor Belt

Oil Resistant Conveyor Belt
EMAIL INQUIRY

Features: transport the oily material or use under Oily environment .

Application：grain、mineral、Recycling plant、Oil refineries and so on.

Technical data：

After the aging test(70℃*168h), at cover rubber rate of “tensile strength at breaking” and “elongation at breaking “,the value change is not over 25% than before

Grade	Breaking Strength，Mpa	Elongation At Break，%	Abrasion，Mm3
L	≥14.0	≥350	≤200
D	≥16.0	≥350	≤160
Note：L----Under the general oil resistant condition；D---Under the high abrasion and oil resistant condition

Cover rubber oil resistant testing.

Note:when you test the oil resistant, choice one of oil in above is ok.

Item	Testing condition			Volume change rate，%
	ASTM 471	Soak temperature，℃	soak time，h	L	D
1	IRM 901	70±2	70±1	+20	-5
2	IRM 902	70±2	70±	+50	+5
3	IRM 903	100±2	22±0.25	+50	+5
